8-09 Double-Layer Bracket Structure Stable High Pressure Centrifugal Fan Sealed Fan Blower

Name: 8-09 Double-Layer Bracket Structure Stable High Pressure Centrifugal Fan Sealed Fan Blower
Brand: Xinxiang SIMO Blower Co., Ltd.
SKU: SIMO Blower 8-09
Availability: InStock

Produktdetails:

Place of Origin:	China
Markenname:	SIMO BLOWER
Zertifizierung:	CE, ISO
Model Number:	SIMO Blower 8-09

Ausführliche Information

Place of Origin:

China

Markenname:

SIMO BLOWER

Zertifizierung:

CE, ISO

Model Number:

SIMO Blower 8-09

Application:

Any industrial setting that requires the transportation of high-pressure and high-temperature gases

Bearing Cooling:

Air Cooling Or Circulating Water Cooling

Blade type:

Backward, Straight, Aerofoil type

Motor:

SIEMENS/ABB/By your demand

Impeller:

Dynamic Balanced

Air Flow:

302-7968㎥/h

Pressure range:

3958-13916Pa

Rotation speedMedium:

≤4000rpm

Feature:

High Performance Strong suction

Impeller support:

SWSI(Single Width, Single Inlet), DWDI(Double Width, Double Inlet), Overhung type

Transport Package:

Standard Export Wooden Case

Production Capacity:

10, 000 Sets/Year

After-Sales Service Provided:

Field Maintenance and Repair Service

Warranty:

1 Year

Key words:

Industrial Fan,High-Pressure Fan,High Pressure Blower,Sealed centrifugal fan

Trading Information

Minimum Order Quantity:

≥1 set

Preis:

$500-1,0000.00/set

Packaging Details:

1.Standard export wooden case 2.steel pallet waterproof cloth package 3.other package to meet your requirement

Delivery Time:

35days (To be negotiated)

Payment Terms:

T/T, L/C, D/P

Supply Ability:

300 Set/Sets per Month centrifugal fan and axial fan manufacturer

Produkt-Beschreibung

8-09 double-layer bracket structure stable high pressure centrifugal fan sealed fan blower

The 8-09 high-pressure small-flow fan is designed for applications that require high pressure. Under the premise of ensuring a certain air volume, the full pressure can meet the high pressure requirements. It is mainly used for forging furnace blasting and other forced air supply, and can also be used for tunnel exhaust or air supply through hard pipes. The fan is divided into ordinary type, explosion-proof type, anti-corrosion type and high temperature resistant type.

The following datas are only part of performance of our product.
If you can't find the datas you need, pls send us your performance requirements
we will provide you customized design service.

PRODUCT PARAMETERS
Application	Temperature	Normal temperature air, Hot air
Application	Air composition	Clean air, Dusty air, Corrosive gas, Combustible gas,Powder materials, Light particle materials
Performance	Impeller diameter	400-1500	mm
	Speed of mainshaft	≤3000	rpm
	Pressure range	3958-13916	Pa
	Flow range	302-7968	m3/h
Structure	Blade	Backward
	Impeller support	SWSI (Single Width, Single Inlet), Impeller overhung.
	Drivetrain	Direct, Coupling, V-belt	Can assign
	Lubrication	Oil bath lubrication	Can assign
	Bearing cooling	Air cooling, Water cooling, Oil cooling
System configuration	Motor	ABB, SIEMENS, WEG, TECO, SIMO, Chinese brand…	Can assign
	Impeller	Q235, Q345, SS304, SS316, HG785, DB685...
	Casing, Air inlet cone, Air inlet damper	Q235, Q345, SS304, SS316, HG785, DB685...
	Main shaft	45# steel(High-strength carbon structural steel), 42CrMo, Stainless steel...
	Bearing	FAG, SKF, NSK, ZWZ…
Optional components	System base frame, Protective screening,Silencer, Inlet & Outlet pipeline compensator, Inlet & Outlet flange, Damper, Electric actuator, Shock isolator, Diaphragm coupling, Fluid coupling, Motor rain cover, Temperature sensor, Vibrating sensor, Soft starter, Inverter, Special Electrical Motor,System monitoring Instrument, Lube system, Overhead lube tank etc

8-09 Double-Layer Bracket Structure Stable High Pressure Centrifugal Fan Sealed Fan Blower 1

8-09 Double-Layer Bracket Structure Stable High Pressure Centrifugal Fan Sealed Fan Blower 2

8-09 Double-Layer Bracket Structure Stable High Pressure Centrifugal Fan Sealed Fan Blower 3

8-09 Double-Layer Bracket Structure Stable High Pressure Centrifugal Fan Sealed Fan Blower 7
